Latest Posts

ETABS-Ghahramani

May 24, 2026, 06:51 AM

🍿 Foundation Properties and Assemblies - SAP2000
💥New💥
📺 720p 🇬🇧
https://www.youtube.com/watch?v=HZs44MY2-Mw💜
In this video, we will discuss how to define and assign Foundation Properties and Foundation Assemblies. A foundation assembly is a parametrically generated collection of components objects (points, lines, areas, and links) intended to represent footings and pile groups, along with the associated soil properties. A foundation assembly will be regenerated whenever the parametric definition is changed. This includes changes made to the properties used by the parametric foundation, as well as geometrical changes to the control points.
1405.02.11
📔📒📕📗📘📙📚📖

1,690

ETABS-Ghahramani

May 24, 2026, 06:51 AM

📷 Photo

The fifth edition of Iranian Standard 2800, the seismic design code for buildings, has been released.
https://www.bhrc.ac.ir/news/ID/21675/
1405.02.14
📔📒📕📗📘📙📚📖

1,940

ETABS-Ghahramani

May 24, 2026, 06:51 AM

🎥 Video

🍿 TECH TIPS: Draw Developed Elevation - ETABS

📺 720p

In this video, we will discus how to draw Developed Elevations in ETABS. Developed Elevations can simultaneously show multiple faces of the building in a single "unfolded" elevation view. We will show the steps to draw a Developed Elevation, which can then be viewed, and if necessary, renamed.
1405.02.05
📔📒📕📗📘📙📚📖

1,780

ETABS-Ghahramani

May 24, 2026, 06:51 AM

📷 Photo

Although ACI 318 has no prescriptive minimum thickness, 8 in (200 mm) is a practical lower limit for special structural walls. Construction and performance generally are imroved if wall thickness is at least 12 in (300 mm) where special boundary elements are used and at least 10 in (250 mm) elsewhere. Walls that incorporate coupling beams require minimum thickness around 14 in (350 mm) to accommodate reinforcement and required cover and bar spacing, although 16 in (400 mm) is a practical minimum where diagonally reinforced coupling beams are used, Flanges and enlarged boundary sections are helpful to stabilize boundaries and anchor reinforcement from adjacent members.
----------------------------------------
ACI318-2025 commentary:
A minimum wall thickness of 300 mm is imposed to reduce the likelihood of lateral instability of the compression zone after spalling of cover concrete.
1405.02.11
📔📒📕📗📘📙📚📖

1,630

ETABS-Ghahramani

May 24, 2026, 06:51 AM

🍿 Codes and Standards for Performance-Based Seismic Design

📺 1080p
https://www.youtube.com/watch?v=arASMKMcR4A💜
In this video, we explore the most important international references for Performance-Based Seismic Design (PBSD) — including ASCE 41, Eurocode 8, TBI Guidelines, and several NIST and FEMA documents.

You’ll learn which standards are most commonly used for nonlinear modeling, pushover analysis, and retrofitting existing buildings — and how they fit into today’s structural engineering practice.
1405.01.17
📔📒📕📗📘📙📚📖

2,400

ETABS-Ghahramani

May 24, 2026, 06:51 AM

📷 Photo

The latest version of SAP2000 is 27.1.0.
Structural Model
Solid elements can now include nonlinear concrete material behavior. Currently a Faria concrete damage plasticity model is available.
Concrete Design
CSA A23.3:2024 concrete frame design is now available.
1405.01.21
📔📒📕📗📘📙📚📖

2,960

ETABS-Ghahramani

May 24, 2026, 06:51 AM

🍿 TECH TIPS: Create Multi-Step Animation Video- SAP2000

In this video, we will discuss the steps to generate a multi-step animation video in SAP2000. Use the Create Multi-Step Animation Video command to create videos in SAP2000 showing the movement of the structure after a time history analysis has been run. The videos are saved as . AVI files.

📺 1080p 🇬🇧
https://www.youtube.com/watch?v=GFCi0TfkasM💜
1405.01.15
📔📒📕📗📘📙📚📖

2,040

ETABS-Ghahramani

May 24, 2026, 06:51 AM

🍿 TECH TIPS: Merge Analysis Results - SAP2000
In this video we will discuss the Merge Analysis Results option in SAP2000.
Multiple copies of the same model can be run on different machines, and the analysis results merged together on a single machine for performing design and processing results. This can be particularly useful when you need to run a large number of load cases (e.g., earthquakes for performance-based design, moving load cases for bridge design, etc.), and there are multiple machines available for running different load cases simultaneously.
https://www.youtube.com/watch?v=eO-j5K33Xn4💜
1405.01.14
📔📒📕📗📘📙📚📖

2,050

ETABS-Ghahramani

May 24, 2026, 06:51 AM

🍿 Drift Check in ETABS

📺 1080p
https://www.youtube.com/watch?v=NBNDcKUG0vs💜
Drift control can govern your design — especially in moment frame buildings.

In this video, we’ll walk through:
🔸 Where to find story drift results in ETABS
🔸 How to calculate the allowable drift from ASCE 7 Table 12.12-1
🔸 Using Cd and story height (h) to find drift limits
🔸 When to use average vs. maximum drift
🔸 How to check drift visually with the Story Response Plot
1405.01.13
📔📒📕📗📘📙📚📖

2,490

ETABS-Ghahramani

May 24, 2026, 06:51 AM

🍿 Torsional Irregularity Check in ETABS

📺 1080p
https://www.youtube.com/watch?v=zfXoq8hzBC4💜
Does your structure have torsional irregularity?

In this short clip, we walk through how to:
🔹 Access the Max-over-Average drift ratios in ETABS
🔹 Use load cases EXPN and EYPN for the check
🔹 Compare the values to ASCE 7 limits
🔹 Confirm if the structure passes or fails the torsional irregularity requirement

This check is based on ASCE 7-22 Section 12.3.2 and Tables 12.3-1 & 12.3-1a.
1405.01.13
📔📒📕📗📘📙📚📖

1,580

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🍿 Check Column Rebar Limits in ETABS

📺 1080p
https://www.youtube.com/watch?v=hNGU7O_wgcs💜
Let’s check longitudinal reinforcement limits in ETABS based on ACI 318-19, Section 18.7:

✔️ Minimum: 1%
✔️ Maximum: 6% at splice zones (→ 3% elsewhere if all bars are lapped)

Here's how to check in ETABS:
1️⃣ Go to Design : Concrete Frame Design : Display Design Info
2️⃣ Select Total Rebar Percentage
3️⃣ Hide beams to clearly see column values
4️⃣ For precise data, open Tables : Design Data : Concrete Column PMM Envelope
5️⃣ Sort by Rebar % and spot values exceeding 3%

📌 If you see columns with over 3% rebar, increase their size to reduce congestion.
1405.01.13
📔📒📕📗📘📙📚📖

1,120

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🍿 How to Scale Base Shear in Response Spectrum Analysis

📺 1080p
https://www.youtube.com/watch?v=MaoRjcIwUcE💜
Finished your response spectrum analysis?
Now it’s time to scale the base shear to meet code requirements.

In this clip, you'll learn how to:
🔹 Extract static and dynamic base shear from ETABS tables
🔹 Calculate scaling factors based on ASCE 7-22 Section http://12.9.1.4/
🔹 Apply the new scale factors to SX, SY, SXPN, and SYPN load cases
🔹 Rerun the analysis with updated values

This step ensures your dynamic results are code-compliant and safe to use in design.
1404.01.13
📔📒📕📗📘📙📚📖

1,200

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🍿 Seismic Response Spectrum Analysis in ETABS 22 | ASCE 7-22 (20-Story Building Example)

📺 1080p
https://www.youtube.com/watch?v=sJ4UOmPKwxo💜
In this ETABS tutorial, we walk through how to define response spectrum functions and load cases based on the ASCE 7-22 code. You'll learn how to apply scale factors using I/R × g, and define load cases in both X and Y directions. We also explain how to set up additional load cases for base shear scaling.

This step is essential for accurate seismic analysis and design of multi-story buildings. Perfect for structural engineers working on performance-based design or preparing for real-world projects.
1405.01.13
📔📒📕📗📘📙📚📖

1,340

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🍿 Calculate the Analytical Time Period in ETABS

📺 1080p
https://www.youtube.com/watch?v=oDptYqLQ7N8💜
Before running a full analysis, it’s essential to calculate the analytical period (T) of your building and compare it to Cu × Ta, as required by code.

In this clip, you’ll learn how to:
🔹 Create a separate ETABS model just for period calculation
🔹 Adjust stiffness modifiers for service-level analysis (0.5 for beams, 1.0 for columns)
🔹 Run only the modal analysis to get Tx and Ty
🔹 Compare T values with Cu × Ta from ASCE 7
🔹 Update the seismic load pattern periods in your main model file

This step ensures your model reflects the correct dynamic behavior before final analysis.
1404.12.14
📔📒📕📗📘📙📚📖

1,990

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🍿 A Fast Way to Draw Strip Footings in SAFE

📺 1080p
https://www.youtube.com/watch?v=kv3jXVguY3M💜
Want a quick way to model strip footings in SAFE?

Instead of manually drawing and adjusting each footing strip, try this smarter approach — draw beams along the footing centerlines and convert them to slab areas.

In this tutorial, we’ll walk you through:
✅ Defining a dummy beam with footing dimensions
✅ Connecting columns using beam centerlines
✅ Converting beams to slab areas in just a few clicks
✅ Deleting extra elements and cleaning up the layout

This method saves a ton of time — especially for projects with lots of footings.
1404.12.14
📔📒📕📗📘📙📚📖

1,620

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🍿 How to Draw Strip and Mat Foundations in SAFE

📺 1080p
https://www.youtube.com/watch?v=zoVudkQUKRA💜
Learn how to draw strip footings and mat foundations in SAFE using the Draw Rectangular Floor/Wall tool.

This tutorial walks you through the full process — from selecting the right slab section to adjusting coordinates using Align Joints.

We also compare the steps for strip footings and mat (raft) foundations, so you’ll know exactly how to model both types efficiently.
This is a must-know technique for foundation design.
1404.12.14
📔📒📕📗📘📙📚📖

1,310

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🍿 How to Draw Design Strips in SAFE | Complete Guide for Foundation Reinforcement

📺 1080p
https://www.youtube.com/watch?v=BJucXkri16w💜
In this video, we walk step-by-step through one of the most important tasks in SAFE foundation modeling — drawing design strips accurately.

You’ll learn how to set snap options, choose the proper strip layer (A, B, or Other), and understand the difference between column strips and middle strips.

We go over how strip width works, how to center or offset strips, and how to handle rectangular or trapezoidal widths.

This tutorial also shows how to draw continuous strips across multiple spans, how to stop strips at elevator pits or shafts, and how to use the Extend tool to properly reach the foundation edges.

By the end of this video, you’ll be able to model clean, accurate, and fully constructible design strips for foundations — ensuring SAFE produces reliable reinforcement layouts for your project.

1404.12.14
📔📒📕📗📘📙📚📖

1,280

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🍿 AI Modelling in Etabs

📺 720p
https://www.youtube.com/watch?v=JGsf81tx0Vw💜
In this video, I demonstrate how Artificial Intelligence is transforming structural modelling in ETABS and how engineers can leverage AI-driven workflows to improve speed, accuracy, and efficiency in building analysis and design.

You will learn:

✔ How AI enhances structural modelling in ETABS
✔ Smart modelling workflows for faster project delivery
✔ How to reduce modelling errors using automation
✔ Practical tips for structural engineers and students
1404.12.14
📔📒📕📗📘📙📚📖

1,500

ETABS-Ghahramani

May 9, 2026, 09:41 PM

🎥 Video

🍿 Structural Design of Tall Buildings
📺 720p
طراحی سازه ای ساختمانهای بلند
دکتر Naveed Anwar
1404.12.13
📔📒📕📗📘📙📚📖

1,970

ETABS-Ghahramani

May 2, 2026, 10:47 AM

از اصلاحات مهم ETABS 23.2.0 :
An incident was resolved for ACI 318-25 and ACI 318-19 concrete column design where envelope shear rebar area in the minor direction could be incorrect when governing load combination does not include a seismic load.
دانلود مستقیم ETABS 23.2.0 از سایت شرکت CSI:
https://www.csiamerica.com/software/ETABS/23/ETABSv2320Build4400Setup.exe
https://www.youtube.com/watch?v=QbQMlckXMpE1404.12.08
📔📒📕📗📘📙📚📖

2,300

ETABS-Ghahramani

Apr 22, 2026, 05:42 PM

🍿 TECH TIPS: Auto Draw Cladding Option

📺 1080p
In this video, we will discuss the capabilities of the Auto Draw Cladding option in ETABS. The "cladding" consists of shell objects, with a None section property, that are added around the outermost perimeter of the structure. The cladding objects have no self weight or structural properties. These objects are intended to be selected before assigning a Wind Pressure Coefficient to apply wind load to the structure. We will go through an example.
https://www.youtube.com/watch?v=QbQMlckXMpE1404.12.08
📔📒📕📗📘📙📚📖

2,100

ETABS-Ghahramani

Apr 22, 2026, 05:42 PM

ورژن های جدید ETABS و SAFE منتشر شده اند.
ETABS 23.2.0
SAFE 23.2.0
👈 بیشتر استاندارد طراحی کره یا KDS اضافه شده است.
ETABS 23.2.0 Enhancement:
🟢Concrete frame design for Eurocode 2023 edition and KDS 14 20 00 : 2022 are now available.
🟢Steel frame design for EN 1993-1-1:2022 and KDS 14 20 00 : 2022 are now available.
🟢Shear Wall design, reinforced concrete and PT slab design for KDS 14 20 00 :2022 are now available.
🟢Composite column design according to KDS 14 31 80 : 2022 is now available.
🟢Composite beam design according to KDS 31 80 14 : 2022 is now available.
🟢Auto-seismic loading and response spectrum functions according to KDS 41 17 00:2024 have been added.
🟢Auto-wind loading, auto-seismic loading, and response-spectrum functions based on NBCC 2025 have been added.

SAFE 23.2.0 Enhancement:
🔴Reinforced concrete and PT slab design for KDS 14 20 00 : 2022 are now available.
https://www.youtube.com/watch?v=QbQMlckXMpE1404.12.08
📔📒📕📗📘📙📚📖

2,000

ETABS-Ghahramani

Apr 22, 2026, 05:42 PM

🍿 TECH TIPS: Import/Export of IFC files in ETABS

📺 1080p
In this video, we will go through examples of how to import/export IFC files in ETABS.
IFC files are repositories of Building Information Modeling (BIM) data. Various types of IFC data are organized into subsets named “views” which gather data types relevant to various aspects of building design, construction, and maintenance. There are several such views, but only two views are relevant to ETABS : the “structural analysis view”, and the “architectural coordination view”.
https://www.youtube.com/watch?v=w7rVA_Yl0MY1404.12.08
📔📒📕📗📘📙📚📖

1,990

ETABS-Ghahramani

Apr 9, 2026, 08:39 AM

📷 Photo

🔎 تغییر در تعریف گره محصورشده در ACI 318-25 نسبت به ACI 318-19

در ویرایش 2019، محصورشدگی گره تیر–ستون عمدتاً بر اساس عرض تیر، امتداد آن و حداقل آرماتور کنترل می‌شد (کنترل تک‌بعدی).

در ویرایش 2025، علاوه بر شرط عرض، یک الزام جدید اضافه شده است:
تیر عرضی باید حداقل 75٪ سطح حاصل‌ضرب عرض وجه ستون در عمق تیر عمیق‌تر (در جهت برش گره) را در صفحه گره پوشش دهد.

📌 بنابراین کنترل از حالت خطی به کنترل سطح مؤثر در صفحه گره ارتقاء یافته است.

بر اساس Commentary و شکل Fig. R15.5.1.1، این اصلاح در راستای تفکیک اعضای مولد برش گره از اعضای تأمین‌کننده محصورشدگی و تعیین دقیق‌تر مقاومت اسمی برش گره انجام شده است.

✅ نتیجه:
این اصلاح از نظر رفتاری بسیار معنادار است:

1️⃣ جلوگیری از حالتی که تیر باریک ولی عمیق باشد و عرض مؤثر کافی نداشته باشد.
2️⃣ جلوگیری از حالتی که عرض مناسب باشد اما عمق مؤثر در جهت برش گره کافی نباشد.
3️⃣ تأکید بر رفتار سه‌بعدی گره تیر–ستون در انتقال برش گره.
4️⃣ محدود کردن اتکای صرف به کنترل عرض تیر و الزام به تأمین سطح مؤثر در صفحه گره.
1404.11.28
📔📒📕📗📘📙📚📖

3,950

ETABS-Ghahramani

Apr 9, 2026, 08:39 AM

📷 Photo

The U. S. code minimum column dimension is 12 in (300 mm), which is often not practical to construct. A 16-in (400-mm) minimum dimension is suggested except for unusual cases or for low-rise buildings.
👈 توجه نمائید که همیشه حداقل ابعاد پیشنهادی آئین نامه معیار نیست. مثلا" آئین نامه حداقل بعد ستون را ۱۲ اینچ یا ۳۰ سانتی متر گفته ولی اغلب برای ساخت عملی نیست. لذا حداقل بعد ۴۰ سانتی متر پیشنهاد شده است.
منبع: کتاب طراحی لرزه ای ساختمانهای بتن آرمه نوشته پرفسور جک میلی
1404.12.02
📔📒📕📗📘📙📚📖

3,350

ETABS-Ghahramani

Apr 4, 2026, 06:16 PM

📷 Photo

🔎 شفاف‌سازی دیوارهای فلنج‌دار (بالدار) در ACI 318-25
ویرایش 2025 مفاهیم مربوط به رفتار لرزه‌ای دیوارهای T و L شکل را به‌صورت شفاف‌تر و تصویری‌تر ارائه کرده است.
📌 شکل R18.10.6.4b
اگر در تحلیل، کرنش/تنش فشاری در فلنج از حد مجاز عبور کند، اجرای Special Boundary Element در همان ناحیه الزامی است.
یعنی Boundary فقط محدود به لبه وب نیست؛ فلنج هم می‌تواند ناحیه بحرانی باشد.
📌 شکل R18.10.6.5b
اتصال web و flange یک ناحیه سه‌بعدی بحرانی است و باید با آرماتور عرضی درگیرکننده هر دو بخش محصور شود تا از جداشدگی در زلزله شدید جلوگیری گردد.
آرماتور عرضی این ناحیه:
از باز شدن ترک‌ها جلوگیری می‌کند
از کمانش میلگردهای طولی جلوگیری می‌کند
رفتار شکل‌پذیر را تضمین می‌کند
✅ جمع‌بندی:
آنچه در ACI 318-25 اضافه شده، ارائه شکل‌های توضیحی جدید در بخش Commentary (از جمله Fig. R18.10.6.4b و Fig. R18.10.6.5b) است که نحوه تشکیل ناحیه بحرانی در فلنج و جزئیات آرماتورگذاری در محل تقاطع web–flange را شفاف‌تر نمایش می‌دهد، بدون آنکه تغییر ماهوی در فلسفه طراحی ایجاد شده باشد.
1404.11.27
📔📒📕📗📘📙📚📖

2,930

Showing 26 of 26 posts

No more posts

Loading posts...

Rating

User Reviews (0)

No reviews yet. Be the first to share your experience!

Loading reviews...

Related Telegram Channels

Loading recommended channels...

ETABS-Ghahramani

ETABS-Ghahramani

Ranking

Participant Growth (Last 6 Days)

Latest Posts

Rating

User Reviews (0)

Related Telegram Channels

Mechanical engineering Gate Ese, ssc je, rrb je premium notes,test series

HAFSA

𝗔𝗣𝗞 𝗘𝗗𝗜𝗧𝗢𝗥 𝗣𝗥𝗢℡

TechLead Bits

Fiskal tahlillar

Pentester

Automotive - Boats - Aircrafts - Tanks - Trains

HackThePlanet

Related Telegram Channels

Mechanical engineering Gate Ese, ssc je, rrb je premium notes,test series

HAFSA

𝗔𝗣𝗞 𝗘𝗗𝗜𝗧𝗢𝗥 𝗣𝗥𝗢℡

TechLead Bits

Fiskal tahlillar

Pentester

Automotive - Boats - Aircrafts - Tanks - Trains

HackThePlanet

User Reviews (0)

Latest Posts
